Precision Copper Flat Wire Machine

GRM Precision Copper Flat Wire Machine is an integrated production line for manufacturing high-precision copper flat wire used in magnet wire, transformer conductors, CTC conductors and EV motor applications. The line combines wire drawing, precision rolling, online measurement, polishing, dust collection and automatic take-up into one continuous process.

Integrated Copper Flat Wire Production Solution

Designed by Jiangsu Goodroller Machinery Co., Ltd. (GRM), this system helps manufacturers improve production efficiency, reduce manual handling and maintain stable dimensional consistency during long production cycles.

Key Production Process

Vertical coil payoff for stable wire feeding
Six-die drawing machine for copper wire preparation
Multiple two-roll precision rolling mills for thickness control
Side rolling mills for width and edge control
Online polishing and dust collection for better surface quality
Online thickness and width measurement for real-time quality control
Transverse take-up machine for automatic winding

Why Choose GRM Precision Copper Flat Wire Machine?

High Dimensional Accuracy

Thickness tolerance up to ±0.005 mm
Width tolerance up to ±0.01 mm
Suitable for demanding electrical conductor applications

Continuous and Efficient Production

Maximum design speed: 400 m/min
Integrated drawing and rolling process reduces intermediate handling
Stable product consistency for large-scale production

Customizable Line Configuration

GRM can customize the production line according to input wire diameter, finished flat wire size, material requirements and downstream application needs.

Precision Copper Flat Wire Machine

Technical Specifications

Configuration	5-stands rolling mill line
First two-high mill	Ø300 mm
First edger mill	Ø155 mm
Second two-high mill	Ø200 mm
Second edger mill	Ø155 mm
Third two-high mill	Ø160 mm
Design speed	Up to 400 m/min
Maximum inlet wire diameter	Ø8 mm
Finished tolerance	Thickness: ±0.005 mm; Width: ±0.01 mm
Typical finished flat wire size	Thickness: 0.5–4.0 mm; Width: 2.0–12 mm

Line Configuration

1 set vertical coil payoff stand
1 set DLF6D/500 six-die drawing machine
3 sets two-roll precision rolling mills
2 sets side rolling mills
1 set online polishing and dust collection device
1 set online thickness and width measuring device
1 set transverse take-up machine

Applications of Precision Copper Flat Wire Machine

Enameled rectangular magnet wire
Transformer copper flat conductor
CTC continuously transposed conductor
EV motor hairpin conductor
EV motor flat wire production

GRM Manufacturing Strength

16 years of experience in metal forming technology
National High-Tech Enterprise certification
EU CE certified equipment solutions
More than 50 product patents
In-house R&D, machining and quality control capabilities
Experience serving electronics, photovoltaic, automotive and electrical industries

Quality Control and Engineering Support

GRM uses CNC machining centers, laser precision tools and automated production systems to support stable equipment manufacturing. The engineering team provides process consultation, 3D modeling, customized line design and technical support based on customer production requirements.

FAQ

Can this line produce copper flat wire for transformer applications?

Yes. The line is suitable for transformer conductors, magnet wire, CTC conductors and other electrical copper flat wire applications.

Is the Precision Copper Flat Wire Machine customizable?

Yes. GRM can customize the machine configuration according to inlet wire diameter, finished wire dimensions, tolerance requirements and production capacity.

What accuracy can the rolling process achieve?

The system can achieve thickness tolerance up to ±0.005 mm and width tolerance up to ±0.01 mm under suitable production conditions.

Why use an integrated drawing and rolling line?

Compared with separate machines, an integrated line reduces material handling, improves production continuity and helps maintain more stable dimensional consistency.

Request a Customized Copper Flat Wire Production Solution

Tell GRM your material specification, inlet wire diameter, finished wire size, tolerance target and application. Our engineering team can provide technical consultation and a customized production line proposal.

Hot Products

Four-High Rolling Mill
A Four-High Rolling Mill from GRM Rolling Mill factory is a metal processing equipment consisting of two parallel, smaller diameter horizontal work rolls and two larger diameter support rolls used to support the work rolls. High relative stiffness, which can effectively control the dimensional accuracy and plate shape of the rolled piece; The large amount of compression can cause significant deformation of metal materials; Low rolling force, capable of rolling thinner plates, suitable for various metal materials such as plain carbon steel, alloy steel, stainless steel, copper, aluminum, etc
CTC Continuously Transposed Conductor Line
The GRM Rolling Mill CTC Continuously Transposed Conductor Line boasts stable operation and high precision, supports speed adjustment and customized configurations, and is widely applicable to precision wire production in transformer, new energy vehicle, home appliance, medical, and aerospace electrical fields. Contact us!
Profile Rolling Machine
Manufactured by the GRM Rolling Mill factory, the GRM-X Series Profile Rolling Machine is an advanced piece of rolling equipment characterized by its high precision and exceptional flexibility. Boasting key advantages such as precise positioning via servo motors, one-touch automatic roll gap calibration, and a modular design featuring both universal and specialized rolls, this machine is ideally suited for diverse sectors—including construction and shipbuilding. It is engineered to meet the rigorous demands of high-end profile manufacturing and supports the customization of profiles with specialized cross-sections.
High-Precision Micro Flat Wire Rolling Mill
The China High-Precision Micro Flat Wire Rolling Mill, developed by GRM Rolling Mill, is a high-end precision machining equipment specifically designed for the thinning and forming of ultra-fine non-ferrous metals (such as pure copper, silver-plated/tin-plated/nickel-copper wire) in fields such as medical wires, electronic information, precision instruments, and high-end connectors. This equipment integrates precision rolling, intelligent control, and high-speed production, making it a core piece of equipment for achieving domestic substitution and industrial upgrading of micro-fine flat wires.
Two High Rolling Machine
GRM Two High Rolling Machine is a compact and versatile metal forming machine designed for reducing thickness, adjusting cross-sectional dimensions, and shaping various metal wires, strips, and profiles.
The machine consists of two horizontally arranged work rolls. During operation, the material passes through the roll gap and undergoes controlled plastic deformation under rolling pressure, achieving the required thickness reduction, width adjustment, or profile forming.
The Two High Rolling Mill can be used as a standalone rolling unit for material development and small-batch production, or integrated into GRM continuous rolling lines according to specific production requirements.
Single Stand Multi-Groove Reducing Rolling Mill
GRM Rolling Mill offers a high-quality Single Stand Multi-Groove Reducing Rolling Mill. This equipment utilizes flexible multi-groove rolling technology, making it an ideal solution for laboratory material testing, small-batch prototyping, and multi-specification processing.
1. Stable dimensional control
2. Adjustable rolling speed
